Gates® 8GS-16FDHORX90M

Gates® GlobalSpiral™ 8GS-16FDHORX90M TuffCoat® Steel Female DIN Heavy 24 deg Cone Swivel Crimp Hose 90 deg Medium Drop Elbow with O-Ring, 1/2 in x 16 mm

Manufacturer: Gates Corp
Brand: Gates®
ARGPN: 8GS-16FDHORX90M

MPN: 8GS-16FDHORX90M

Available for delivery:
Available for pickup at Anchorage, AK Branch:
Sold As: 1/PK
Add to cart

Description
Specs
Features
Documents

Gates® GlobalSpiral™ Crimp Hose 90 deg Medium Drop Elbow with O-Ring, Connection Type 1: Hose, Connection Size 1: 1/2 in, Hose Dash Size: 08, Connection Type 2: DIN Heavy 24 deg Cone Swivel, Gender 2: Female, Connection Size 2: 16 mm, Nominal Size: 16 mm, Thread Size 2: M24 x 1.5, Hex Size: 30 mm, 6000 psi, Cut-Off Factor: 1.91 in, Material Construction: Steel, Finish: TuffCoat®, Dimension Standards: ISO Draft International Standards 12151-2, 250 deg F

Connection Size 1	:	1/2 in
Connection Size 2	:	16 mm
Connection Type	:	Hose~DIN Heavy Female Swivel
Connection Type 1	:	Hose
Connection Type 2	:	DIN Heavy 24 deg Cone Swivel
Cut-Off Factor	:	1.91 in
Dimension Standards	:	ISO Draft International Standards 12151-2
Finish	:	TuffCoat®
Fitting Type	:	90 deg Elbow
Gender 2	:	Female
Hex Size	:	30 mm
Hose Dash Size	:	08
Material	:	Steel
Material Construction	:	Steel
Nominal Size	:	16 mm
Pressure Rating	:	6000 psi
Shape	:	90 deg Elbow
Sub Brand	:	GlobalSpiral™
Temperature Rating	:	250 deg F
Thread Size 2	:	M24 x 1.5

Gates® GlobalSpiral™ couplings provide superior performance for extremely high-pressure, high-impulse spiral-wire hydraulic hose applications. The innovative two-piece, no-skive design allows for fast, tailor made assemblies. Eliminating the skiving process drastically reduces assembly time, labor, odor, fabrication errors and contamination of the fluid power system. Coated with TuffCoat® plating more than 5x better corrosion resistance than SAE ASTM B117 specification.

Unique bite-the-wire crimp design allows for improved coupling retention and blow-off prevention
Reduces parts inventory by 30% since only one stem is required for all spiral-wire hose types
Surpasses one million impulse cycles
One stem used for all spiral hoses
