Stucchi 800601008
Stucchi IRB Series 800601008 Interchange Coupler, 3/4 in Quick-Disconnect x 3/4 in FNPT, Steel
- Manufacturer: Stucchi USA
- Brand: Stucchi
- ARGPN: 800601008
- MPN: 800601008
-
Available for delivery:
-
Available for pickup at
Anchorage, AK Branch:
-
Available for Stucchi USA factory-direct delivery:
-
The IRB Series quick-couplings are interchangeable to ISO B standard (ISO 7241-B). The IRB is offered in three different high quality materials to meet different application challenges IRB carbon steel with nitrile seals, IRBO brass with FKM seals and IRBX 316 stainless steel with FKM seals. The entire Series features compact design, AISI 302 stainless steel springs and PTFE anti-extrusion rings.
Stucchi Interchange Coupler, Series: IRB Series, Coupler Fitting, Connection Size 1: 3/4 in, Connection Type 1: Quick-Disconnect, Connection Size 2: 3/4 in, Connection Type 2: FNPT, Quick-Disconnect|FNPT Connection, Steel, Carbon Steel Material Construction, 1.42 in Hex, Dimension Standards: ISO B, 3.55 in L x 1.97 in H, 4000 psi Maximum Operating Pressure
| Connection Size 1 | : | 3/4 in |
| Connection Size 2 | : | 3/4 in |
| Connection Type | : | Quick-Disconnect|FNPT |
| Connection Type 1 | : | Quick-Disconnect |
| Connection Type 2 | : | FNPT |
| Dimension Standards | : | ISO B |
| Dimensions | : | 3.55 in L x 1.97 in H |
| Fitting Type | : | Coupler |
| Hex Size | : | 1.42 in |
| Material | : | Steel |
| Material Construction | : | Carbon Steel |
| Maximum Operating Pressure | : | 4000 psi |
| Series | : | IRB Series |
