OPW® Civacon 610 Stainless Steel Vapor Recovery Adapter without Poppet or Sight Glass, 4 in Adapter x 4 in TTMA Flange

OPW® 610F

  • Manufacturers: Dover Corporation
  • Brand Name: OPW®
  • ARGPN: 610F
  • MPN: 610F
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Branch Availability: loading
  • Total Availability: loading
  • Availability: Typically Ships in 3-5 days

OPW® Civacon Vapor Recovery Adapter without Poppet or Sight Glass, Series: 610, Connection Type 1: Fitting, Connection Size 1: 4 in, Connection Type 2: TTMA Flange, Connection Size 2: 4 in, Material Construction: Stainless Steel

Connection Size 1      :      4 in
Connection Size 2      :      4 in
Connection Type 1      :      Fitting
Connection Type 2      :      TTMA Flange
Material      :      Stainless Steel
Material Construction      :      Stainless Steel
Series      :      610
Shape      :      Adapter
Sub Brand      :      Civacon

The 610 Series non-poppeted vapor recovery adaptors contain the vapors and condensation within the vapor line, minimizing unwanted driver exposure and vapor loss into the atmosphere.

  • Drilled-mounting pad for optional air interlock valve
  • 3 in vapor recovery piping on smaller tank trucks is easily accommodated with standard reducers (pipe or flanged)
  • The F model Series feature a 1/4 in NPT brass drain plug

Prop Warning API RP 1004 Certified|European EN13083 Standard

  • pdfCatalog https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/CIVACON_60TT_CAT.pdf
  • pdfCut sheet https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/CIVACON_610F_SS.pdf
  • pdfTechnical Drawing/Parts Diagram https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/CIVACON_610F_TD.pdf
