Mikalor 0301362-2

Mikalor Supra W5 316 Stainless Steel Heavy-Duty T-Bolt Hose Clamp, 19 - 21 mm, 18 mm W

  1. pin-int

Mikalor Heavy-Duty T-Bolt Hose Clamp, Series: Supra W5, 21 mm Maximum Clamp Diameter, 19 mm Minimum Clamp Diameter, Locking Style: Bolt, Torque Rating: 10 N-m, Material Construction: 316 Stainless Steel, 18 mm Width

Locking Style      :      Bolt
Material      :      Stainless Steel
Material Construction      :      316 Stainless Steel
Maximum Clamp Diameter      :      21 mm
Minimum Clamp Diameter      :      19 mm
Product Type      :      T-Bolt Clamp
Series      :      Supra W5
Torque Rating      :      10 N-m
Width      :      18 mm

The Supra range is the natural evolution of the Super W1 clamp. Due to its revolutionary swiveling bridge, the Supra W5 clamp can be mounted in the most awkward applications without having to remove the hose. Once mounted, it can be opened up and fastened again without dislodging or losing any of the other components of the clamp, making assembly much easier. Thanks to the beveled edges, the hose is protected from damage. The Supra W5 clamp complies fully with RoHs directive EU 2002/95/EC dated 1st July 2006. The AISI 316 stainless steel bolt together with the captive nut and spacer system allow you to clamp the most demanding of assemblies. Supra W5 is a full stainless steel clamp destined for demanding applications where very high corrosion-resistance is vital. This top of the range heavy-duty clamp is ideal for marine applications, foodstuff manufacture, pharmaceutical and petrochemical industries and other applications where AISI 316 stainless steel fittings are required.

  • pdfCatalog https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Mikalor_0301577-5_CAT.pdf
  • pdfCut sheet https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Mikalor_0301361-4_SS.pdf
