Hansen™ and Gromelle™ Poppet Valve, Series: 5100, Connection Type 1: Threaded, Connection Size 1: 1 in, Up to 500 psi, Material Construction: Brass, Finish: Zinc Trivalent-Plated, Dimensions: 0.671 in L x 1.11 in W x 1.11 in H, -40 to 250 deg F
| Connection Size 1 |
: |
1 in |
| Connection Type 1 |
: |
Threaded |
| Dimensions |
: |
0.671 in L x 1.11 in W x 1.11 in H |
| Finish |
: |
Zinc Trivalent-Plated |
| Material |
: |
Brass |
| Material Construction |
: |
Brass |
| Pressure Rating |
: |
Up to 500 psi |
| Series |
: |
5100 |
| Shape |
: |
Valve |
| Temperature Rating |
: |
-40 to 250 deg F |
Eaton's 5100 Series brass coupling with steel tubular valve offers minimum air inclusion and fluid loss. Thread together latch provides connect under pressure capability and vibration-resistance. The 5100 series is not rated for continuous hydraulic impulse applications.
- No fluid loss during connection/disconnection
- Low air inclusion
- Wing or hex configuration
Applications: Hydraulics and fluid transfer, on-highway hydraulic wet lines, dump and refuse vehicles and bulk liquid transfer
-
Catalog
https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Hansen_and_Gromelle_5100-15-16B_CAT.pdf
