Dixon® Vent-Lock™ L300-A-SS 316 Stainless Steel Safety Cam and Groove Adapter, 3 in Male Type A x 3 in FNPT

Dixon® L300-A-SS

  • Manufacturers: Dixon Valve & Coupling
  • Brand Name: Dixon®
  • ARGPN: L300-A-SS
  • MPN: L300-A-SS
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Branch Availability: loading
  • Total Availability: loading
  • Availability: Typically Ships in 3-5 days
  • Prop WarningCalifornia residents see Prop 65 WARNINGS

Dixon® Vent-Lock™ Safety Cam and Groove Adapter, Connection Type 1: Type A, Gender 1: Male, Connection Size 1: 3 in, Connection Type 2: NPT, Gender 2: Female, Connection Size 2: 3 in, Thread Size 2: 3-8, Hex Size: 3-3/4 in, 150 psi, Material Construction: 316 Stainless Steel, Dimensions: 2-29/32 in L, 70 deg F, For Use With: Ferrules, Sleeves, Bands and Other Reliable Attachment Options

Connection Size 1      :      3 in
Connection Size 2      :      3 in
Connection Type 1      :      Type A
Connection Type 2      :      NPT
Dimensions      :      2-29/32 in L
For Use With      :      Ferrules, Sleeves, Bands and Other Reliable Attachment Options
Gender 1      :      Male
Gender 2      :      Female
Hex Size      :      3-3/4 in
Material      :      Stainless Steel
Material Construction      :      316 Stainless Steel
Pressure Rating      :      150 psi
Shape      :      Adapter
Sub Brand      :      Vent-Lock™
Temperature Rating      :      70 deg F
Thread Size 2      :      3-8
  • Safety release cam and groove couplings permit the release of static pressure when disconnecting hose assemblies
  • Venting system protects operator from being sprayed with hazardous or non-hazardous fluids or solids

Applications: Transfer of fluids and solids, with a safe disconnection

Safety Notes:

  • Pressure rating recommendation is based on the use of mating Vent-Lock™ L-style fittings at ambient temperature 70 deg F with standard Buna-N seal installed, for use at elevated temperature or other unusual operating conditions, consult Dixon®.
  • Does not interchange with standard cam and groove products use only with Vent-Lock™ L-style fittings.
