Dixon® IXH32 Carbon Steel Internal Expansion Heavy-Duty Coupling, 2 in Hose x 2 in Raised End

Dixon® IXH32

  • Manufacturers: Dixon Valve & Coupling
  • Brand Name: Dixon®
  • ARGPN: IXH32
  • MPN: IXH32
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Branch Availability: loading
  • Total Availability: loading
  • Availability: Typically Ships in 3-5 days
  • Prop WarningCalifornia residents see Prop 65 WARNINGS

Dixon® Internal Expansion Heavy-Duty Coupling, Connection Type 1: Hose, Connection Size 1: 2 in, Connection Type 2: Raised End, Connection Size 2: 2 in, 800 psi, Material Construction: Carbon Steel, 5-5/8 in Length

Connection Size 1      :      2 in
Connection Size 2      :      2 in
Connection Type 1      :      Hose
Connection Type 2      :      Raised End
Length      :      5-5/8 in
Material      :      Steel
Material Construction      :      Carbon Steel
Pressure Rating      :      800 psi
Shape      :      Coupling
  • Internally expanded couplings are essential when maximum flow of media is important
  • Reduces turbulence through hose
  • Excellent sealing and retention characteristics
  • Outperforms band clamps
  • Easy and consistent installation

Safety Notes: Dixon® Holedall stems and ferrules are specifically designed to be used together as a coupling system. Due to differences in dimensions and tolerances, for safety reasons, do not use other manufacturer's stems or ferrules with Dixon® Holedall products.

  • Do not use a wrench or vice on ferrule.
  • Holedall couplings, regardless of coupling style, are never to be used for steam service at any pressure.
  • Holedall fittings are not to be used with cable reinforced high-pressure hose, 4 or 6 braid wire hydraulic hose or any other service not listed in the recommendations.
  • Consult Dixon® for recommendations on usage.
  • Strict adherence to ferrule OD range (Internally Expanded) for each hose end to be assembled is essential for satisfactory performance.
  • Internally expanded holedall couplings are not to be used with plastic lined chemical hose.
  • Hose service working pressure (including surges and spikes) is never to exceed the maximum recommended working pressure for the fitting.
  • The assembly's (hose + coupling) maximum working pressure is the lesser of the hose rated working pressure or the coupling rated working pressure.
  • Media being transported through the hose should be compatible with the stem material.
  • Compatibility of ferrule material with the environment in which it will be used is recommended.
  • Consult the compatibility chart or the Dixon® factory for material compatibility.
  • For applications other than the ones list, please consult Dixon.
  • Maximum recommended working pressures, in PSI, given at 70 deg F ambient temperature.

    Applications: For concrete placement, grout and plaster, food, dairy, pharmaceutical as well as other applications where increased flow capacity is important, contact Dixon for additional application and working pressure information
