Dixon® BV2IGN15033-A BV2IGN15033-A

Dixon® BV2IGN15033-A

Dixon® BV2IGN15033-A CF8M Stainless Steel 3-Piece Full-Port Ball Valve, 1-1/2 in Socket Weld/FPT, 1000 psi

  • Manufacturer: Dixon Valve & Coupling
  • Brand: Dixon®
  • ARGPN: BV2IGN15033-A
  • MPN: BV2IGN15033-A
  • ARG Industrial Available for delivery: loading
  • ARG Industrial Available for pickup at Anchorage, AK Branch: loading
  • loading
  • Add to cart
Add To Favorites
  1. pin-int

Dixon® 3-Piece Full-Port Ball Valve, Nominal Size: 1-1/2 in, Connection Type: Socket Weld/FPT, Material Construction: CF8M Stainless Steel, 316 Stainless Steel Stem, 15% Glass Reinforced RTFE Seat Trim, 4.4 in Length, 4-1/2 in Width, 400 deg F, 1000 psi

California residents see Prop 65 WARNINGS

Connection Type      :      Socket Weld/FPT
Length      :      4.4 in
Material      :      Stainless Steel
Material Construction      :      CF8M Stainless Steel
Nominal Size      :      1-1/2 in
Pressure Rating      :      1000 psi
Product Type      :      Ball Valve
Temperature Rating      :      400 deg F
Trim Material      :      316 Stainless Steel Stem, 15% Glass Reinforced RTFE Seat
Width      :      4-1/2 in
  • Blowout-proof stem design
  • Live loaded stem packing
  • Swing out design for easy maintenance

Applications: Industrial applications

  • pdfCatalog https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_SSBV100SR_CAT_NEW2021.pdf
  • pdfTechnical Drawing/Parts Diagram https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_BV2IGN15033-A_TD.pdf
