Dixon® 688-24
Dixon® 688-24 Hydraulic Suction and Return Line Stem, 1-1/2 in Hose x 1-1/2 in Female SAE 37 deg JIC Swivel, Steel
- Manufacturer: Dixon Valve & Coupling
- Brand: Dixon®
- ARGPN: 688-24
- MPN: 688-24
-
Available for delivery:
-
Available for pickup at
Anchorage, AK Branch:
-
Available for Dixon Valve & Coupling factory-direct delivery:
-
Dixon® Hydraulic Suction and Return Line Stem, Fitting Type: Stem, Connection Size 1: 1-1/2 in, Connection Type 1: Hose, Connection Size 2: 1-1/2 in, Connection Type 2: Female SAE 37 deg JIC Swivel, Connection Type: Hose|Female JIC Swivel, Hose Dash Size: 24, Steel, Material Construction: Steel, 1-7/8-12 Thread, 2-1/4 in Hex
| Connection Size 1 | : | 1-1/2 in |
| Connection Size 2 | : | 1-1/2 in |
| Connection Type | : | Hose|Female JIC Swivel |
| Connection Type 1 | : | Hose |
| Connection Type 2 | : | Female SAE 37 deg JIC Swivel |
| Fitting Type | : | Stem |
| Hex Size | : | 2-1/4 in |
| Hose Dash Size | : | 24 |
| Material | : | Steel |
| Material Construction | : | Steel |
| Thread Size | : | 1-7/8-12 |
- Barbs provide easy assembly and maximum gripping action
- Return line clamps must be used with these fittings
