Coxreels EZ-TMP-450
Coxreels EZ-TMP-450 Spring Driven Hose Reel, 50 ft Hose, 1/2 in ID x 13/16 in OD Dia Hose, Medium Pressure Hose
- Manufacturer: Coxreels
- Brand: Coxreels
- ARGPN: COX-EZ-TMP-450
- MPN: EZ-TMP-450
-
Available for delivery:
-
Available for pickup at
Anchorage, AK Branch:
-
Available for Coxreels factory-direct delivery:
-
COXREELS® EZ-T Series "truck-mount" spring driven hose reels are the toughest hose reels in the spring driven line. The extra large chassis with dual pedestal-style arms and COXREELS® Super Hub™ provides triple axle support while reducing vibration and strengthening the structural integrity of the reel. Making it perfect for off-road applications that demand reliability in the most abusive and demanding environments.
Coxreels Spring Driven Hose Reel, Series: EZ-T Series, 50 ft Hose, 1/2 in ID x 13/16 in OD Hose Dia, Medium Pressure Hose, NPT Swivel Connection Type, Ratchet Locking Style, Steel, Powder-Coated, 2500 psi, Ceiling, Floor, Vehicle, Wall Mount, 19-1/2 in L x 9-3/8 in W x 21-1/4 in H, Additional Information: 9 in L x 8 in W Base, NBR Seal
| Additional Information | : | 9 in L x 8 in W Base, NBR Seal |
| Connection Type | : | NPT Swivel |
| Dimensions | : | 19-1/2 in L x 9-3/8 in W x 21-1/4 in H |
| Finish | : | Powder-Coated |
| Hose Capacity | : | 50 ft |
| Hose Diameter | : | 1/2 in ID x 13/16 in OD |
| Hose Type | : | Medium Pressure |
| Locking Style | : | Ratchet |
| Material | : | Steel |
| Mounting Type | : | Ceiling, Floor, Vehicle, Wall |
| Pressure Rating | : | 2500 psi |
| Series | : | EZ-T Series |
- Professional grade heavy-duty steel construction
- Rolled edges and ribbed discs provide strength and safety
- Machined from solid brass 90 deg full flow NPT swivel for simple seal maintenance and fast and easy hose installation, no need to remove the reel from its mount
- Lubricated and enclosed cartridge-style motor is easily removable for safe and convenient maintenance, COXREELS® patented safety system that retracts up to 80% slower than conventional reels
- Heavy-duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection and operator safety
- Sturdy dual pedestal design with solid one-piece steel base and support post, no weld, for maximum stability, equipped with COXREELS® exclusive Super Hub™ triple axle support
- Multi-position guide arm - versatile guide arm adjusts to wall, floor, ceiling and vehicle-mounting positions
- Long-lasting, chip-resistant and rust inhibiting CPC™ powder-coat finish, adjustable solid rubber hose stop and sturdy permanently lubricated precision bearings
- Made in USA
