Adaptall 9325-02-10X1.5
Adaptall 9325 Series 9325-02-10X1.5 Straight Adapter, 1/8 in MNPT x 10 mm Female Metric, Steel
- Manufacturer: Adaptall Inc.
- Brand: Adaptall
- ARGPN: ADA-9325-02-10X1.5
- MPN: 9325-02-10X1.5
-
Available for delivery:
-
Available for pickup at
Anchorage, AK Branch:
-
Available for Adaptall Inc. factory-direct delivery:
-
Adaptall Straight Adapter, Series: 9325 Series, Adapter Fitting, Connection Size 1: 1/8 in, Connection Type 1: MNPT, Connection Size 2: 10 mm, Connection Type 2: Female Metric, MNPT|Female Metric Connection, Steel, Carbon Steel Material Construction, 1/8-27 x M10x1.5 Thread, 14 mm Hex, Dimension Standards: ANSI B1.20.3, DIN 7631, 32.2 mm L
| Connection Size 1 | : | 1/8 in |
| Connection Size 2 | : | 10 mm |
| Connection Type | : | MNPT|Female Metric |
| Connection Type 1 | : | MNPT |
| Connection Type 2 | : | Female Metric |
| Dimension Standards | : | ANSI B1.20.3, DIN 7631 |
| Dimensions | : | 32.2 mm L |
| Fitting Type | : | Adapter |
| Hex Size | : | 14 mm |
| Material | : | Steel |
| Material Construction | : | Carbon Steel |
| Series | : | 9325 Series |
| Thread Size | : | 1/8-27 x M10x1.5 |
