Weatherhead® E-Z Clip System™ Straight Hose Fitting, Series: FJ5984, Connection Type 1: Hose, Gender 1: Male, Connection Size 1: 3/4 in, Hose Dash Size: 12, Connection Type 2: O-Ring Short Pilot, Gender 2: Female, Connection Size 2: 3/4 in, Thread Size 2: 1-1/16-16, Hex Size: 1-1/4 in, Material Construction: Carbon Steel, Finish: Zinc Clear Trivalent Chromate, For Use With: GH134 Series Hoses, Dimensions: 3.14 in L x 0.75 in W x 0.75 in H, Dimension Standards: SAE J2064 Type E, Class 1
| Connection Size 1 |
: |
3/4 in |
| Connection Size 2 |
: |
3/4 in |
| Connection Type 1 |
: |
Hose |
| Connection Type 2 |
: |
O-Ring Short Pilot |
| Dimension Standards |
: |
SAE J2064 Type E, Class 1 |
| Dimensions |
: |
3.14 in L x 0.75 in W x 0.75 in H |
| Finish |
: |
Zinc Clear Trivalent Chromate |
| For Use With |
: |
GH134 Series Hoses |
| Gender 1 |
: |
Male |
| Gender 2 |
: |
Female |
| Hex Size |
: |
1-1/4 in |
| Hose Dash Size |
: |
12 |
| Material |
: |
Steel |
| Material Construction |
: |
Carbon Steel |
| Series |
: |
FJ5984 |
| Shape |
: |
Straight Hose Fitting |
| Sub Brand |
: |
E-Z Clip System™ |
| Thread Size 2 |
: |
1-1/16-16 |
Applications: For sustainable approach to designing hydraulic systems
-
