Weatherhead® 1866X6
  1. pin-int

Weatherhead® 1800 CA360 Brass Quick-Connect Air Brake Straight Connector, 1.69 in L, 3/8 in Push-to-Connect x 1/4 in FNPT

Weatherhead® 1866X6

  • Manufacturers: Danfoss Power Solutions
  • Brand Name: Weatherhead®
  • ARGPN: 1866X6
  • MPN: 1866X6
  • UPC: 725975659977
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Branch Availability: loading
  • Total Availability: loading
  • Availability: Typically Ships in 3-5 days

  • Prop WarningCalifornia residents see Prop 65 WARNINGS

Weatherhead® Quick-Connect Air Brake Straight Connector, Series: 1800, Connection Type 1: Push-to-Connect, Connection Size 1: 3/8 in, Connection Type 2: NPT, Gender 2: Female, Connection Size 2: 1/4 in, Hex Size: 11/16 in, 150 psi, Material Construction: CA360 Brass, Dimensions: 1.69 in L x 0.69 in W x 0.79 in H, -40 to 200 deg F, For Use With: SAE J844 Type A and B NT Air Braking Tubing

Connection Size 1      :      3/8 in
Connection Size 2      :      1/4 in
Connection Type 1      :      Push-to-Connect
Connection Type 2      :      NPT
Dimensions      :      1.69 in L x 0.69 in W x 0.79 in H
For Use With      :      SAE J844 Type A and B NT Air Braking Tubing
Gender 2      :      Female
Hex Size      :      11/16 in
Material      :      Brass
Material Construction      :      CA360 Brass
Pressure Rating      :      150 psi
Series      :      1800
Shape      :      Air Brake Connector
Temperature Rating      :      -40 to 200 deg F
  • Moderate vibration resistance

Applications: Air brake systems except where temperatures exceed 2000 deg F or where battery acid can drip on tubing

Prop Warning DOT FMVSS 571.106 Approved|Prop65 Warning: This product contains lead and other chemicals which are known to the state of California to cause cancer and birth defects or other reproductive harm @www.P65Warnings.ca.gov|SAE J1131 Certified

  • pdfCatalog https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Weatherhead_1477X6_CAT.pdf
