WIKA® 9767266

Liquid Filled Pressure Gauge, 2-1/2 in Dial, 0 - 3000 psi Back Mount

  • Manufacturer: WIKA Instrument
  • Brand: WIKA®
  • ARGPN: 9767266
  • MPN: 9767266
  • ARG Industrial Available for delivery: loading
  • ARG Industrial Available for pickup at Anchorage, AK Branch: loading
  • loading
  • Add to cart
  1. pin-int

WIKA® Liquid Filled Pressure Gauge, Series: 213.53, Measuring System: psi, Pressure Range: 0 - 3000 psi, Connection Size: 1/4 in NPT, 2-1/2 in Dial Size, +/-2/1/2% Span Accuracy, -20 to 60 deg C Ambient, 60 deg C Media, Analog Display, Center Back Mount, 304 Stainless Steel Case, Plastic Pointer, Finish: Natural, Dimensions: 2.2 in D

Accuracy      :      +/-2/1/2% Span
Case Material      :      304 Stainless Steel
Connection Size      :      1/4 in NPT
Dial Size      :      2-1/2 in
Dimensions      :      2.2 in D
Display Type      :      Analog
Finish      :      Natural
Measuring System      :      psi
Mounting Type      :      Center Back
Pointer Material      :      Plastic
Pressure Range      :      0 - 3000 psi
Product Type      :      Pressure Gauge
Series      :      213.53
Temperature Rating      :      -20 to 60 deg C Ambient, 60 deg C Media

The liquid filled model 213.53 Bourdon tube pressure gauge is constructed with a case from stainless steel and wetted parts from copper alloy. The liquid filled gauge 213.53 meets the requirements of the international industry standard EN 837-1 for Bourdon tube pressure gauges. Due to the liquid filling in the case, the pressure element and movement are efficiently damped. Therefore, these instruments are particularly suited to measuring points with high dynamic loads, such as fast load cycles or vibrations. The cases of the liquid filled gauge 213.53 are available in nominal sizes of 50, 63 and 100 mm and fulfil IP65 ingress protection. With an accuracy of up to class 1.0, this pressure gauge is suitable for a wide range of applications in industry. For mounting in control panels, the pressure gauges with a back-mount process connection can be fitted with a mounting flange or with a triangular bezel and mounting bracket.

  • Vibration and shock-resistant
  • Especially robust design
  • Type approval for the shipbuilding industry
  • Bourdon tube
  • Pressure limitation - 3/4 x full scale value steady, 2/3 x full scale value fluctuating, full scale value short time
  • Process connection - copper alloy
  • Movement - copper alloy
  • ABS dial, white with pointer stop pin
  • Case sealing towards process connection with O-ring, with all scale ranges, the filling plug can be vented for internal pressure compensation
  • Position of blow-out device - case circumference, at 12 o'clock
  • Window - plastic, crystal-clear
  • Ring - crimped triangular bezel, stainless steel, glossy finish
  • Fill liquid glycerin

Applications: For measuring points with high dynamic pressure loads and vibrations, gaseous and liquid media that are not highly viscous or crystallizing and will not attack copper alloy parts, hydraulics, compressors, shipbuilding

  • pdfCatalog https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/WIKA_4236557_CAT.pdf
  • pdfCut sheet https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/WIKA_4236557_SS.pdf
  • pdfInstallation Instructions https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/WIKA_4236557_II.pdf
