Gates® 3658-1977
  1. pin-int

Gates® 10C5M Black Type C Nitrile Hydraulic Marine Fuel Line Hose, 1/2 in, 3 ft L, 500 psi

Gates® 3658-1977

  • Manufacturers: Gates Corp
  • Brand Name: Gates®
  • ARGPN: 10C5M
  • MPN: 3658-1977
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Branch Availability: loading
  • Total Availability: loading
  • Availability: Typically Ships in 3-5 days

Gates® Hydraulic Marine Fuel Line Hose, Series: 10C5M, Nominal Size: 1/2 in, 0.92 in OD, 1/2 in ID, 3 ft Length, 500 psi, Material Construction: Type C Nitrile, Type C2 Nitrile Cover, Construction: Braided, Black, 2.3 in Bend Radius, Resistance Properties: Flame, High Oil, -4 deg F Low, 212 deg F High

Bend Radius      :      2.3 in
Color      :      Black
Construction      :      Braided
Cover Material      :      Type C2 Nitrile
Inside Diameter      :      1/2 in
Length      :      3 ft
Material      :      Nitrile
Material Construction      :      Type C Nitrile
Nominal Size      :      1/2 in
Outside Diameter      :      0.92 in
Pressure Rating      :      500 psi
Product Type      :      Fuel Line Hose
Resistance Properties      :      Flame, High Oil
Series      :      10C5M
Temperature High      :      212 deg F
Temperature Low      :      -4 deg F
  • One-wire braid reinforcement
  • Braided, high-tensile steel wire
  • 4:1 design factor

Applications: For all commercial, recreational vessel fuel line, B100 biodiesel, gasohol fuels, on-shore/off-shore, marine diesel fuel, gasoline and hot oil lines applications

Prop Warning ABS Approved|ARPM Class A, Class C Certified|MSHA 2G Specified|SAE J1942/J1527/J30R2 Certified|USCG Type A, Class 1, Style R3 Specified

  • pdfCatalog https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Gates_3658-1969_CAT.pdf
