Weatherhead® E-Z Clip System™ FJ5985 Zinc Clear Trivalent Chromate Carbon Steel Female O-Ring Short Pilot 90 deg Elbow, 1/2 in

Weatherhead® FJ5985-0808S

  • Manufacturers: Danfoss Power Solutions
  • Brand Name: Weatherhead®
  • ARGPN: FJ5985-0808S
  • MPN: FJ5985-0808S
  • UPC: 678146013903
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Branch Availability: loading
  • Total Availability: loading
  • Availability: Typically Ships in 3-5 days

Weatherhead® E-Z Clip System™ 90 deg Elbow, Series: FJ5985, Connection Type 1: Hose, Connection Size 1: 1/2 in, Hose Dash Size: 08, Connection Type 2: O-Ring Short Pilot, Gender 2: Female, Connection Size 2: 1/2 in, Thread Size 2: 3/4-16, Hex Size: 7/8 x 1 in, Material Construction: Carbon Steel, Finish: Zinc Clear Trivalent Chromate, For Use With: GH134 Multi-Refrigerant Hoses, Dimensions: 3.77 in L x 0.88 in W x 1.62 in H, Dimension Standards: SAE J2064 Type E, Class 1

Connection Size 1      :      1/2 in
Connection Size 2      :      1/2 in
Connection Type 1      :      Hose
Connection Type 2      :      O-Ring Short Pilot
Dimension Standards      :      SAE J2064 Type E, Class 1
Dimensions      :      3.77 in L x 0.88 in W x 1.62 in H
Finish      :      Zinc Clear Trivalent Chromate
For Use With      :      GH134 Multi-Refrigerant Hoses
Gender 2      :      Female
Hex Size      :      7/8 x 1 in
Hose Dash Size      :      08
Material      :      Steel
Material Construction      :      Carbon Steel
Series      :      FJ5985
Shape      :      90 deg Elbow
Sub Brand      :      E-Z Clip System™
Thread Size 2      :      3/4-16
  • E-Z to use and virtually leak-free
  • Simplicity of design, easy-to-use

Applications: Air conditioning systems, both in vehicle and commercial applications

Prop Warning SAE J2064 Type E, Class 1 Certified
