Weatherhead® Crimp Hose 90 deg Long Drop Elbow, Series: Coll-O-Crimp E, Connection Type 1: Hose, Gender 1: Female, Connection Size 1: 1/2 in, Hose Dash Size: 08, Connection Type 2: SAE 37 deg JIC Swivel, Gender 2: Female, Connection Size 2: 1/2 in, Nominal Size: 1/2 in, Thread Size 2: 3/4-16, Hex Size: 7/8 x 3/4 in, 4000 psi, Cut-Off Factor: 1.78 in, Material Construction: Carbon Steel, Finish: Zinc Clear Trivalent Chromate, For Use With: H009, H209, H243, H265, H275, H277, H285, H435, H436, S-TW, and SC-TW Series PTFE Hoses, Dimensions: 3.32 in L x 0.95 in W x 3.3 in H
| Connection Size 1 |
: |
1/2 in |
| Connection Size 2 |
: |
1/2 in |
| Connection Type |
: |
Hose~JIC Female Swivel |
| Connection Type 1 |
: |
Hose |
| Connection Type 2 |
: |
SAE 37 deg JIC Swivel |
| Cut-Off Factor |
: |
1.78 in |
| Dimensions |
: |
3.32 in L x 0.95 in W x 3.3 in H |
| Finish |
: |
Yellow Zinc Dichromate |
| Fitting Type |
: |
90 deg Elbow |
| For Use With |
: |
H009, H209, H243, H265, H275, H277, H285, H435, H436, S-TW, and SC-TW Series PTFE Hoses |
| Gender 2 |
: |
Female |
| Hex Size |
: |
7/8 x 3/4 in |
| Hose Dash Size |
: |
08 |
| Material |
: |
Steel |
| Material Construction |
: |
Carbon Steel |
| Nominal Size |
: |
1/2 in |
| Pressure Rating |
: |
4000 psi |
| Series |
: |
Coll-O-Crimp E |
| Shape |
: |
90 deg Elbow |
| Thread Size 2 |
: |
3/4-16 |
Applications: General-purpose low and medium-pressure hydraulics
-
Catalog
https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Weatherhead_03E-102_CAT.pdf
