Weatherhead® Crimp Hose 90 deg Elbow, Series: Coll-O-Crimp E, Connection Type 1: Hose, Connection Size 1: 1/4 in, Hose Dash Size: 04, Connection Type 2: Inverted Swivel, Gender 2: Male, Connection Size 2: 3/16 in, Nominal Size: 3/16 in, Thread Size 2: 3/8-24, Hex Size: 7/16 x 3/8 in, Cut-Off Factor: 1.38 in, Material Construction: Carbon Steel, Finish: Yellow Zinc Dichromate, For Use With: H009, H209, H243, H265, H275, H277, H285, H435, H436, S-TW, and SC-TW Series PTFE Hoses, Dimensions: 2.51 in L x 0.57 in W x 1.34 in H
| Connection Size 1 |
: |
1/4 in |
| Connection Size 2 |
: |
3/16 in |
| Connection Type |
: |
Hose~Inverted Flare Male Swivel |
| Connection Type 1 |
: |
Hose |
| Connection Type 2 |
: |
Inverted Swivel |
| Cut-Off Factor |
: |
1.38 in |
| Dimensions |
: |
2.51 in L x 0.57 in W x 1.34 in H |
| Finish |
: |
Yellow Zinc Dichromate |
| Fitting Type |
: |
90 deg Elbow |
| For Use With |
: |
H009, H209, H243, H265, H275, H277, H285, H435, H436, S-TW, and SC-TW Series PTFE Hoses |
| Gender 2 |
: |
Male |
| Hex Size |
: |
7/16 x 3/8 in |
| Hose Dash Size |
: |
04 |
| Material |
: |
Steel |
| Material Construction |
: |
Carbon Steel |
| Nominal Size |
: |
3/16 in |
| Series |
: |
Coll-O-Crimp E |
| Shape |
: |
90 deg Elbow |
| Thread Size 2 |
: |
3/8-24 |
Applications: General-purpose low and medium-pressure hydraulics
-
Catalog
https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Weatherhead_75706E-Z06_CAT_New.pdf
