Synflex® 37AL-08-250BX
  1. pin-int

Synflex® 37AL Orange Polyester Non-Conductive Aerial Lift Hose, 1/2 in, 1 ft L, 3000 psi

Synflex® 37AL-08-250BX

  • Manufacturers: Danfoss Power Solutions
  • Brand Name: Synflex®
  • ARGPN: 37AL-08-250BX
  • MPN: 37AL-08-250BX
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Branch Availability: loading
  • Total Availability: loading
  • Availability: Typically Ships in 3-5 days

Synflex® Non-Conductive Aerial Lift Hose, Series: 37AL, Nominal Size: 1/2 in, Dash Size: 08, 0.82 in OD, 1/2 in ID, 21 ft Length, 3000 psi, SAE Rating: SAE 100R7, Material Construction: Co-Polyester, Polyurethane Cover, Construction: Braided Synthetic Fiber, Orange, 3 in Bend Radius, -65 deg F Low, 212 deg F High

Bend Radius      :      3 in
Color      :      Orange
Construction      :      Braided Synthetic Fiber
Cover Material      :      Polyurethane
Dash Size      :      08
Inside Diameter      :      1/2 in
Length      :      250 ft
Material      :      Polyester
Material Construction      :      Co-Polyester
Nominal Size      :      1/2 in
Outside Diameter      :      0.82 in
Pressure Rating      :      3000 psi
Product Type      :      Aerial Lift Hose
SAE Rating      :      SAE 100R7
Series      :      37AL
Temperature High      :      212 deg F
Temperature Low      :      -65 deg F
  • Low volumetric expansion - less than +/-2%

Applications: Electric utility truck, hydraulic systems, mobile equipment (pickers, utility vehicles)

Prop Warning ANSI A92.2 Specified
