Hansen™ and Gromelle™ 1000 Brass Coupling, 1/4 in Female Quick Disconnect x 3/8 in Male Hose Barb

Hansen™ and Gromelle™ 1700E

  • Manufacturers: Danfoss Power Solutions
  • Brand Name: Hansen™ and Gromelle™
  • ARGPN: 1700E
  • MPN: 1700E
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Branch Availability: loading
  • Total Availability: loading
  • Availability: Typically Ships in 3-5 days

Hansen™ and Gromelle™ Coupling, Series: 1000, Connection Type 1: Quick Disconnect, Gender 1: Female, Connection Size 1: 1/4 in, Connection Type 2: Hose Barb, Gender 2: Male, Connection Size 2: 3/8 in, Hex Size: 25.4 mm, 2000 psi at 70 deg F, Material Construction: Brass, Dimensions: 2.6 in L x 1 in W, -40 to 250 deg F, For Use With: Compressed Air, Gas, and Liquid

Connection Size 1      :      1/4 in
Connection Size 2      :      3/8 in
Connection Type 1      :      Quick Disconnect
Connection Type 2      :      Hose Barb
Dimensions      :      2.6 in L x 1 in W
For Use With      :      Compressed Air, Gas, and Liquid
Gender 1      :      Female
Gender 2      :      Male
Hex Size      :      25.4 mm
Material      :      Brass
Material Construction      :      Brass
Pressure Rating      :      2000 psi at 70 deg F
Series      :      1000
Shape      :      Coupling
Temperature Rating      :      -40 to 250 deg F

Eaton’s 1000 Series is an industrial interchange pneumatic coupling that is rugged and reliable designed for use with compressed air, gases and liquids.

  • Ball latching mechanism
  • All sizes accept US industrial interchange
  • Buna-N seal material

Applications: Construction, fluid transfer, general pneumatics, industrial plants

Prop Warning Mil-A-A-59439 Specified

  • pdfCatalog https://www.alaskarubbergroup.com//ASSETS/DOCUMENTS/ITEMS/EN/Hansen_and_Gromelle_3L28P15_CAT.pdf
