BrakeQuip® BQ172 Aluminum Braze-On Adapter, 23 mm L, 3/4-16 Weld-On UNF 37 deg JIC x 1/2 in Tube

BrakeQuip® BQ172

  • Manufacturers: BrakeQuip
  • Brand Name: BrakeQuip®
  • ARGPN: BQ172
  • MPN: BQ172
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Branch Availability: loading
  • Total Availability: loading
  • Availability: Typically Ships in 3-5 days

BrakeQuip® Braze-On Adapter, 23 mm Length, Connection Type 1: UNF 37 deg JIC, Connection Size 1: 3/4-16, Connection Type 2: Tube, Connection Size 2: 1/2 in, Material Construction: Aluminum, 16.7 mm Stud Length, Hex Size: 13/16 in

Connection Size 1      :      3/4-16
Connection Size 2      :      1/2 in
Connection Type 1      :      UNF 37 deg JIC
Connection Type 2      :      Tube
Hex Size      :      13/16 in
Length      :      23 mm
Material      :      Aluminum
Material Construction      :      Aluminum
Product Type      :      Adapter
Stud Length      :      16.7 mm

The ultimate convenience item for aluminum tubes found on air conditioning and oil cooler lines. This problem solver will make it easy to connect aluminum tube to flexible hose. The pre-fluxed aluminum brazing rods BQ34 are ideal for brazing these fittings.

Applications: For oil cooler and A/C lines
